Code NameJUNE CANYON EssentialsBoard Form FactorUCFF (4" x 4")SocketSoldered-down BGAInternal Drive Form Factor2.5" Drive# of Internal Drives Supported1Lithography14 nmTDP10 WDC Input Voltage Supported12-19 VDCProcessor IncludedIntel Celeron Processor J4005 (4M Cache, up to 2.70...
przeczytaj całość
Code Name |
JUNE CANYON |
Essentials |
Board Form Factor |
UCFF (4" x 4") |
Socket |
Soldered-down BGA |
Internal Drive Form Factor |
2.5" Drive |
# of Internal Drives Supported |
1 |
Lithography |
14 nm |
TDP |
10 W |
DC Input Voltage Supported |
12-19 VDC |
Processor Included |
Intel Celeron Processor J4005 (4M Cache, up to 2.70 GHz) |
Warranty Period |
3 yrs |
Supplemental Information |
Embedded Options Available |
No |
Description |
Other features: Includes SDXC card slot, dual microphones |
Memory & Storage |
Max Memory Size (dependent on memory type) |
8 GB |
Memory Types |
DDR4-2400 1.2V SO-DIMM |
Max # of Memory Channels |
2 |
Max Memory Bandwidth |
38.4 GB/s |
Max # of DIMMs |
2 |
ECC Memory Supported ‡ |
No |
Processor Graphics |
Integrated Graphics ‡ |
Yes |
Graphics Output |
2x HDMI 2.0a |
# of Displays Supported ‡ |
2 |
Expansion Options |
Removable Memory Card Slot |
SDXC with UHS-I support |
I/O Specifications |
# of USB Ports |
6 |
USB Configuration |
2x front and 2x rear USB 3.0; 2x USB 2.0 via internal headers |
USB Revision |
2.0, 3.0 |
USB 2.0 Configuration (External + Internal) |
0 + 2 |
USB 3.0 Configuration (External + Internal) |
2B 2F + 0 |
Total # of SATA Ports |
1 |
Max # of SATA 6.0 Gb/s Ports |
1 |
RAID Configuration |
N/A |
Audio (back channel + front channel) |
7.1 digital; L+R+mic (F); L+R+TOSLINK (R) |
Integrated LAN |
10/100/1000 |
Integrated Wireless‡ |
Intel Wireless-AC MAC |
Integrated Bluetooth |
Yes |
Consumer Infrared Rx Sensor |
Yes |
S/PDIF Out Connector |
TOSLINK |
Additional Headers |
CEC, 2x USB2.0, AUX_PWR, FRONT_PANEL |
Package Specifications |
Low Halogen Options Available |
See MDDS |
Advanced Technologies |
Intel Virtualization Technology for Directed I/O (VT-d) ‡ |
Yes |
Intel vPro™ Technology ‡ |
No |
TPM |
No |
Intel HD Audio Technology |
Yes |
Security & Reliability |
Intel AES New Instructions |
Yes |
