1. Intel H310 Express Chipset

1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory


2. Dual channel memory architecture


3. Support for DDR4 2666/2400/2133 MHz memory modules


4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)


5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
   To support 2666 MHz, you must install a 9th or 8th Generation Intel Core™ i9/i7/i5 processor(Please refer "Memory Support List" for more information.)

Integrated Graphics Processor-Intel HD Graphics support:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
The DVI-D port does not support D-Sub connection by adapter.
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
Support for DisplayPort 1.2 version, HDCP 2.2, and HDR.
1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
Support for HDMI 1.4 version and HDCP 2.2.
Support for up to 2 displays at the same time
Maximum shared memory of 1 GB

1. Realtek ALC887 codec


2. High Definition Audio


3. 2/4/5.1/7.1-channel
   To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.

1. Realtek GbE LAN chip (10/100/1000 Mbit)

1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
   For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
   (The PCI Express x16 slots conform to PCI Express 3.0 standard.)


2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
   (The PCI Express x4 slot conforms to PCI Express 2.0 standard.)


3. 2 x PCI slots

Chipset:
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA SSD support)
4 x SATA 6Gb/s connectors
Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

1. 4 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)


2. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

1. 1 x 24-pin ATX main power connector


2. 1 x 8-pin ATX 12V power connector


3. 4 x SATA 6Gb/s connectors


4. 1 x CPU fan header


5. 1 x system fan header


6. 1 x front panel header


7. 1 x front panel audio header


8. 1 x USB 3.1 Gen 1 header


9. 2 x USB 2.0/1.1 headers


10. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)


11. 1 x serial port header


12. 1 x parallel port header


13. 1 x Clear CMOS jumper

1. 1 x PS/2 keyboard/mouse port


2. 1 x D-Sub port


3. 1 x DVI-D port


4. 1 x serial port


5. 1 x DisplayPort


6. 1 x HDMI ports


7. 2 x USB 3.1 Gen 1 ports


8. 4 x USB 2.0/1.1 ports


9. 1 x RJ-45 port


10. 3 x audio jacks

1. iTE I/O Controller Chip

1. Voltage detection


2. Temperature detection


3. Fan speed detection


4. Overheating warning


5. Fan fail warning


6. Fan speed control

1. 2 x 128 Mbit flash


2. Use of licensed AMI UEFI BIOS


3. Support for DualBIOS™


4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

1. Support for APP Center
   * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
   @BIOS
   AutoGreen
   Cloud Station
   EasyTune
   Fast Boot
   Game Boost
   ON/OFF Charge
   Platform Power Management
   RGB Fusion
   Smart Backup
   Smart Keyboard
   Smart Survey
   System Information Viewer
   USB Blocker


2. Support for Q-Flash


3. Support for Xpress Install

1. Norton Internet Security (OEM version)


2. cFosSpeed


3. Realtek 8118 Gaming LAN Bandwidth Control Utility

1. Support for Windows 10 64-bit

1. Micro ATX Form Factor; 24.4cm x 22.5cm

1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.


2. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
