1. Support for 10th Generation Intel Core™ i9 processors/Intel Core™ i7 processors/Intel Core™ i5 processors/Intel Core™ i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1200 package


2. L3 cache varies with CPU

1. Intel B460 Express Chipset

1. Intel Core™ i9/i7 processors:
   Support for DDR4 2933/2666/2400/2133 MHz memory modules


2. Intel Core™ i5/i3/Pentium/Celeron processors:
   Support for DDR4 2666/2400/2133 MHz memory modules


3. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory


4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)


5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules


6. Support for Extreme Memory Profile (XMP) memory modules

Integrated Graphics Processor-Intel HD Graphics support:

1. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
   The DVI-D port does not support D-Sub connection by adapter.


2. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
   Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.


3. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
   Support for HDMI 1.4 version and HDCP 2.3.

Support for up to 3 displays at the same time
Maximum shared memory of 512 MB

1. Realtek ALC1200 codec


2. High Definition Audio


3. 2/4/5.1/7.1-channel

1. Intel GbE LAN chip (1000 Mbit/100 Mbit)

1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
   For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.


2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)


3. 1 x PCI Express x1 slot
   (All of the PCI Express slots conform to PCI Express 3.0 standard.)


4. 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)

1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2Q_SB)


2. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2A_SB)


3. 6 x SATA 6Gb/s connectors


4. Support for RAID 0, RAID 1, RAID 5, and RAID 10
   Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.


5. Intel Optane™ Memory Ready
   System Acceleration with Intel Optane™ Memory enabled on the M2Q_SB connector only.

Chipset:

1. 1 x USB Type-C™ port on the back panel, with USB 3.2 Gen 1 support


2. 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)


3. 2 x USB 2.0/1.1 ports on the back panel

Chipset+USB 2.0 Hub:

1. 4 x USB 2.0/1.1 ports available through the internal USB headers

Chipset:

1. 1 x 24-pin ATX main power connector


2. 1 x 8-pin ATX 12V power connector


3. 1 x CPU fan header


4. 3 x system fan headers


5. 2 x addressable LED strip headers


6. 2 x RGB LED strip headers


7. 6 x SATA 6Gb/s connectors


8. 2 x M.2 Socket 3 connectors


9. 1 x front panel header


10. 1 x front panel audio header


11. 1 x USB 3.2 Gen 1 header


12. 2 x USB 2.0/1.1 headers


13. 2 x Thunderbolt™ add-in card connectors


14. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)


15. 1 x serial port header


16. 1 x Clear CMOS jumper


17. 1 x Q-Flash Plus button

Chipset:

1. 1 x PS/2 keyboard/mouse port


2. 1 x DVI-D port


3. 1 x DisplayPort


4. 1 x HDMI port


5. 1 x USB Type-C™ port, with USB 3.2 Gen 1 support


6. 3 x USB 3.2 Gen 1 ports


7. 2 x USB 2.0/1.1 ports


8. 1 x RJ-45 port


9. 6 x audio jacks

1. iTE I/O Controller Chip

1. Voltage detection


2. Temperature detection


3. Fan speed detection


4. Overheating warning


5. Fan fail warning


6. Fan speed control
   Whether the fan speed control function is supported will depend on the cooler you install.

1. 1 x 128 Mbit flash


2. Use of licensed AMI UEFI BIOS


3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

1. Support for APP Center
   Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
   @BIOS
   EasyTune
   Fast Boot
   Game Boost
   ON/OFF Charge
   RGB Fusion
   Smart Backup
   System Information Viewer


2. Support for Q-Flash Plus


3. Support for Q-Flash


4. Support for Xpress Install

1. Norton Internet Security (OEM version)


2. cFosSpeed

1. Support for Windows 10 64-bit

1. Micro ATX Form Factor; 24.4cm x 24.4cm
