2-way : Paper top-exit and front-exit (IPx1)Compact cube : 127mm x 127mm x 127mmMax printing speed : 250mm/secOptional 4.3 inch color LCD can be mounted on RP-F10Easy pairing with a Bluetooth terminal via NFC (Bluetooth Model)Cutter lock automatic restoration mechanismVarious drivers and wide...
przeczytaj całość
2-way : Paper top-exit and front-exit (IPx1)
Compact cube : 127mm x 127mm x 127mm
Max printing speed : 250mm/sec
Optional 4.3 inch color LCD can be mounted on RP-F10
Easy pairing with a Bluetooth terminal via NFC (Bluetooth Model)
Cutter lock automatic restoration mechanism
Various drivers and wide variety utility software
Model |
RP-F10 |
---|
*1 Use recommended thermal papers. *2 Excluding protrusion. ESC/POS™: Registered trademark of SEIKO EPSON CORP. Windows is the registered trademark of Microsoft Corporation(USA). Android™ is a trademark of Google Inc. This product is under development. The specs are subject to change. |
Printing |
Method |
Thermal line dot printing |
---|
Resolution (dpi) |
203 (8dots/mm) |
---|
Paper width (mm) |
58 / 80
|
---|
Printing width (mm) |
54 / 72 |
---|
Speed (mm/sec) max |
250 |
---|
Outside diameter of paper roll (mm) max |
? 83 |
---|
Character matrix (H × W dots) |
24 × 12, 24 × 24, 16 × 8, 16 × 16 |
---|
Character size (H × W mm) |
3.0 × 1.5, 3.0 × 3.0, 2.0 × 1.0, 2.0 × 2.0 |
---|
Type of Paper |
Roll paper |
---|
Character type |
Code page(14pages), International character, Optional font, Downloaded character, JIS 1&2 Level Kanji Special character, User-defined character |
---|
Bar code |
UPC-A/E, JAN(EAN)8/13, ITF, CODABAR, Code39, Code93, Code128, QR, PDF417, GS1 Databar |
---|
Power supply |
Specified AC adapter, External power (DC24±10%) |
---|
Communication interface |
USB+USB-host |
---|
Input buffer |
4K bytes |
---|
Command |
ESC/POS™ conformity |
---|
Cutting |
Method |
Slide type |
---|
Cutting type |
Full cut, Partial cut (Leave center point) |
---|
Operating temperature (°C) |
5 to 45 |
---|
Service life |
Abrasion resistance (km) |
1501
|
---|
Paper cutting (cut) |
1,500,0001
|
---|
Dimensions (W×D×H mm) |
127.0 × 127.0 × 127.0*2
|
---|
Mass (g) |
Approx. 840 |
---|
Standard |
FCC, CE, VCCI |
---|
Option |
Wall mounting Kit, Buzzer, LCD (4.3inch color) |
---|
Cash drawer |
2 drivers (24V / 1A) |
---|
Body color |
2 colors: White / Black |
---|
Software |
Windows : Printer Driver, Virtual COM Driver, OPOS Driver, POS for .Net Driver / SDK / Utility Linux : CUPS Filter (Driver) / Communication Library (SDK) Android™ : SDK / Utility, iOS:SDK/Utility |
---|
